Central Battery Fixture

Radiant

Name: Radiant (RAD)
Brand: Sage EM
SKU: RAD

RAD

A low profile and powerful LED recessed fixture for mounting up to 4 ft from floor level. Dual function operation in either emergency or Normal mode.

DUAL-FUNCTION

Normal or emergency from one fixture.

LOW PROFILE

Recessed, mounts from 4 ft up.

POWERFUL

High output where it's needed.

SAGE LIVE™

Monitored on the central battery.

Documents

Submittal documents for Radiant. Preview inline or download.

Configure your order code below. Click an option to add it to your SKU.

Build Your Order CodeInteractive

Operation

Power

Face Plate Color

Options (select any)

Your Order Code

RAD-CB-10-W

Sample order example: RAD-CB-10-W-LV

Signature Series

Buy American Act compliant and made in the USA. BAA documentation ships with the submittal package.

Build America, Buy America (BABA) compliant. Documentation available for federally funded infrastructure projects.

Specifications

Input Power: 24 VDC from the central battery
Emergency Operation: 90 min or more, central battery
CB: -40 C to 50 C
Power: 10 watts emergency and normal power
Lamp Life: Over 50,000 hours in normal use
Suggested Specification: Install Sage RAD Floor Proximity LED emergency lighting fixture available as a remote device connected to a central battery power source. See Sage central battery (Sage central battery) data sheet. Upon loss of AC building power, emergency models shall operate for a minimum of 90 minutes under battery power, in compliance with UL 924 and NFPA LSC Code 101. The unit may be specified to operate normally on for security or night lighting, as required.
Warranty: 10 year total customer satisfaction warranty. For details see product catalog technical data section. (10/5 mark on sheet.)
