- Input
- Universal 120/277 VAC input for standard battery (BB) or AC unit
- Emergency Runtime
- >= 90 minutes under battery power
- Battery
- Li-ion Battery (BB models); high efficiency charger
- Power Options
- 10 watts emergency and normal power; 20 watts emergency and normal power
- Lamp Life
- Over 50,000 hours in normal use
- Lamp Config
- LEDs connected in parallel; single lamp failure does not disable the fixture
- Protections
- Line latch circuit (prevents unwanted emergency activation at install); Low Voltage Disconnect (LVD, prevents deep battery discharge)
- Cri Cct
- Standard CRI 5000K; optional color correction filters for 2900K, 3200K, 3800K
- BB
- 0°C to 50°C
- AC And RE
- -40°C to 50°C
- Wet Location
- UL wet location, outdoor rated
- Ingress
- IP66 — seals against heavy water spray and fine dust ingress
- Ada
- ADA compliant
- Optics
- Full 90° cut-off
- Warranty
- 10 year total customer satisfaction warranty. For details see product catalog technical data section. (Warranty mark on sheet: 10/5)
- Note
- FOR REFERENCE ONLY. STANDARD REFLECTANCES 80/50/20. IS NOT RESPONSIBLE FOR SPECIFIC CONDITIONS THAT MAY ALTER THE RESULTS. CONTACT FOR LAYOUT ASSISTANCE — Code Compliant Emergency lighting layouts provided free of charge.
- RE Models
- Requires 'SEC' option with central battery.
- BB Models
- Requires option 'SD' for connection to 120/277 VAC.
- General
- Normal-on switch allows timed control of night lighting. The unit may be specified to operate continuously for security or night lighting, as required.
- Suggested Spec Text
- Install ™ Series ASP architectural emergency lighting fixture manufactured by Lighting, Inc. The ASP assembly shall be listed for installation in wet locations in compliance with UL 924 and IP66 standards, available as unit equipment or as a remote connected to a central battery power source. Upon loss of AC building power, lighting will be activated for a minimum of 90 minutes under battery power, in compliance with UL 924 and NFPA LSC Code 101. In remote configuration, the unit may be specified to operate continuously for security or night lighting, as required. The battery charger and power supply shall have universal input of 120/277 VAC, with brownout and LVD circuit protection. Auto battery diagnostics available for all models and shall perform all test functions specified by UL 924 and NFPA 101.
- Photometric Ies
- No photometric/IES file referenced on the sheet. Spacing guide gives reference-only average illuminance of 1 Fc (ASP10 @ 8 1/2' A.F.F.; ASP20 @ 12' A.F.F.) at 80/50/20 standard reflectances. 'Contact for layout assistance — code-compliant emergency lighting layouts provided free of charge.'
